5V DC Mini Electric Linear Valve Actuator for Motor Brass Ball Valve in Shutting off/on Water Meter DN15mm

With the 2-way, mini electric motorized valves, you can control the flow by setting opening degree,fully open,fully closed,30% open,60% open

Feature:

1) Compact design and light weight: It is considered "mini",because it only measures approx 3 inches wide by3 inches tall ,and it only weights approx 0.3~0.5KG/pc.
2) High performance&price ratio:
3) Application&Design: Mini electric ball valve is electrically operated valve used in various automatic water treatment system,water leak alarm & shut off system,it is made of two parts,Electric actuator+Ball valve,the valve will open&close when voltage applies&remove to the motor.

Applications:

-Water saving

-RF type IC card prepay water meter

-Flow control in water treatment

-Automatic drain in central heat supply system

Model K24 Technical data
1. Voltage: DC3.6 V (Range: DC2.5 - 5 V, the higher the voltage, the larger torque, the shorter life span)
2. Current at idling: <25 mA @ 3.6V, 23ºC
3. Current with loading: <450 mA (motor #300)
4. Torque: >1.8 NM (2400:1) / >2.5 NM (3400:1)
5. Open/close time: <10 S (2400:1) / <15 S (3400:1)
6. Velocity reduction ratio: 2400:1 (DN15/20mm), 3400:1 (DN25 mm).
7. Protection: IP66

Definition of wiring terminals:
